LU4C

Universal 4 Screened Luminaire

Natural anodised aluminuim profile with anti-glare screen & clip-on attachement design for easy mounting and removal.

Specifications
Ref
Dimensions
Lighting unit
Connector
Voltage
Power
IP Protection
Length
Data Sheet
LU4CX LU4CX-AC LU4CS LU4CAL LU4CSAL LU4CAL LU4CSAL LU4CAL
Xenon Xenon Soffite Aga-Led@ Type B Aga-Led@ Type B Aga-Led® Type A Aga-Led® Type A Flex Led
Rigid Loop Rigid Loop Festoon Rigid Loop Festoon Rigid Loop Festoon - -
24V 24V 24V 24V 24V 24V 24V 24V
51W/m to 170W/m 54W/m to 180W/m 51W/m to 170W/m 17.28W/m to 21.6W/m 17.28W/m to 21.6W/m 18 W/m 18 W/m 4.8W/m
IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20
up to 3000mm up to 3000mm up to 3000mm up to 3000mm up to 3000mm up to 3000mm up to 3000mm up to 3000mm
Download PDF Download PDF Download PDF Download PDF Download PDF Download PDF Download PDF Download PDF
Finish & Certifications

Finish on request

Natural Anodised Aluminuim
Thermo-Enameling
Powder Coating RAL
Color Anodising
Polished Aluminuim

Certification

LU4C Universal 4 Screened Luminaire full range is certified for
