LU5

Universal 5 luminaire

Natural anodised aluminuim profile designed for directional lighting.

Specifications
Ref
Dimensions
Lighting unit
Connector
Voltage
Power
IP Protection
Length
Data Sheet
LU5X LU5X-AC LU5AL LU5SAL LU5AL
Xenon Xenon Aga-Led@ Type B Aga-Led@ Type B Flex Led
Rigid Loop Rigid Loop Rigid Loop Festoon - -
24V 24V 24V 24V 24V
51W/m to 170W/m 54W/m to 180W/m 16.32W/m to 20.4W/m 16.32W/m to 20.4W/m 4.8W/m
IP20 IP20 IP20 IP20 IP20
up to 3000mm up to 3000mm up to 3000mm up to 3000mm up to 3000mm
Download PDF Download PDF Download PDF Download PDF Download PDF
Finish & Certifications

Finish on request

Natural Anodised Aluminuim
Thermo-Enameling
Powder Coating RAL
Color Anodising
Polished Aluminuim

Certification

LU5 Universal 5 luminaire full range is certified for
